| The model basic parameters of cylindrical lithium-ion battery table | |||||||||||
Model |
Nominal Voltage（V） | Nominal Capacity （MAH） | Dimensions (mm) | Charge&Discharge | Temperature(℃) | Approximate weight(g) | |||||
| Typical | Minimum | Diameter(±0.2) | Height (±0.5) |
Charge current |
Discharge current |
Charge | Discharge | Storage | |||
| IFR32650-3500DP | 3.2 | 3500 | 3400 | 32.5 | 65.5 | 1C | 10-20C | 0~45 | -20-60 | -20-50 | 124.0 |
| IFR32650-4000DY | 3.2 | 4000 | 3800 | 32.5 | 65.5 | 1C | 1-3C | 0~45 | -20-60 | -20-50 | 125.0 |
| D-on behalf of lithium iron phosphate,p on behalf of motive power batteries,Y on behalf of conventional batteries | |||||||||||
